Regressed Square Gimbal Downlight
Phantom M721
1.4 inch
100 lm/W
15 W
±17°, Rotate 360°
Aperture
Efficacy
Power
Tilt
Download
Driver
Finish
Beam Angle
Light Source
Series
M721
1.4" Regressed
Square Gimbal
Downlight
*Minimum Order Quantities Apply
Ordering Code:
Description
The advanced driver and COB system enables M721 to generate 1500 lumens of light with only 15 watts. This high luminous efficacy not only reduces the fixture size, but also extends the lifespan. The optics consist of a 1-3/8 inch aperture lens deeply regressed in a baffle to minimize glare and enhance visual comfort.
Specifications
-
Light Output: 1500 lumens
-
Power: 15W
-
Efficacy: 100 lumens/watt
-
Input Voltage: 120V
-
CCT Selectable: 2700K/3000K/3500K/4000K/5000K
-
CRI: >90 or >95
Specifications
-
Aiming: Tilt ±17°, Rotate 360°
-
Diming: ELV/TRIAC/0-10V diming
-
Lumen Maintenance: 70% @ 60,000 hrs
-
Rating: IC rated, IP54 for wet location
-
Certification: cETLus
-
Warranty: Five years limited warranty
Colour Options
Black
White
Dimensions
General Description
1.4 inch
100 lm/W
15 W
±17°, Rotate 360°
Aperture
Efficacy
Power
Tilt
Phantom M721
1.4” Regressed Square Gimbal Downlight
Download
General Description
Description
The advanced driver and COB system enables M721 to generate 1500 lumens of light with only 15 watts. This high luminous efficacy not only reduces the fixture size, but also extends the lifespan. The optics consist of a 1-3/8 inch aperture lens deeply regressed in a baffle to minimize glare and enhance visual comfort.
Specifications
-
Light Output: 1500 lumens
-
Power: 15W
-
Efficacy: 100 lumens/watt
-
Input Voltage: 120V
-
CCT Selectable: 2700K/3000K/3500K/4000K/5000K
-
CRI: >90 or >95
-
Aiming: Tilt ±17°, Rotate 360°
-
Lumen Maintenance: 70% @ 60,000 hrs
-
Diming: ELV/TRIAC/0-10V diming
-
Rating: IC rated, IP54 for wet location
-
Certification: cETLus
-
Warranty: Five years limited warranty
Dimensions
Colour Options
Black
